Labortaory roj teeb Electrode Slitter

1.Model: TOB-FT300
2.Application: Rau roj teeb electrode slitting
3.Width: 10-300mm adjustable
4.Suitable electrode thickness: 50-400μm
5. Dimension: L850 * W620 * H300 (mm)

Xa kev nug

Tsham tam sim no

Khoom Taw qhia

Labortaory roj teeb Electrode Slitter Nrog Kev Cai Dav

Product Video

Specification

TOB-FT300 roj teeb electrode slitter siv rau electrode yob slitting tom qab xovxwm, nws txais yuav tsis muaj clearance riam rau slitting, hlais ntug zoo, xyuas kom meej qhov tseeb.

Nws muaj xws li nce thiab nqis cutter, tuav, Inlet thiab qhov hluav taws xob positioning phaj, iav, reducer, motor.etc.

Main feature:

* Adjustable qhia ntaus ntawv rau pub qhov chaw;

* Siv hluav taws xob dov txiav sawb;

* Cov nyiaj meshing tuaj yeem hloov kho;

* Sab sauv thiab sab hniav nrog tib ceev, synchronous kis tau tus mob;

* Cov cuab yeej tiv thaiv Plexiglas yog teem rau ntawm lub qhov cub kom muaj kev nyab xeeb;

* Qhib hob tsau hom, yooj yim rau disassemble lub hob;

Qauv	TOB-FT300
Cutter riam hom	Up thiab down round riam
Dav	10-300 hli
Standard cutter	56mm, 56mm, 56mm, 58mm, 58mm.58mm.
Haum thickness	50-400μm roj teeb electrode
Up thiab Down qhov sib txawv	Handwheel kho 0.2-0.4mm
Cutter txoj kab uas hla	85mm ua
Cutter khoom	Ultra-zoo grained alloy steel
Slitting ceev	<2m/min ,adjustable
Qhov hluav taws xob	AC220V / 50Hz (AC110V / 60HZ)
Hwj chim	0.5KW
Dimension	L850 × W 620 × H 300 (mm)
Qhov hnyav	Txog 100KG
