Hnab Cell OCV Sorting Tshuab
Qhov no OCV roj teeb sorting tshuab yog siv rau lub hnab cell. Los ntawm kev luam theej duab QR code ntawm lub roj teeb ntawm tes, nws cov ntaub ntawv hluav taws xob thiab cov ntaub ntawv tiv thaiv sab hauv raug khi, suav nrog kev ua haujlwm coding (lub coding muaj nuj nqi tuaj yeem thaiv), thiab kev ua haujlwm ntawm kev txiav tawm qhov tsis zoo K tus nqi ntawm V2 thiab tsis zoo code scanning ( tau tshaj V1 thiab V2 kev xeem), ib-nias hloov dua siab tshiab) muaj zog xws li cov ntaub ntawv losis tswvyim dabtsi thiab uploading rau lub MES system, uas yuav ua tau raws li cov kev xav tau ntawm ntau yam kev ua hauj lwm.
Hnab Cell OCV Sorting Tshuab
Product Video
Specification
Basic Functions
Qhov no OCV roj teeb sorting tshuab yog siv rau lub hnab cell. Los ntawm kev luam theej duab QR code ntawm lub roj teeb ntawm tes, nws cov ntaub ntawv hluav taws xob thiab cov ntaub ntawv tiv thaiv sab hauv raug khi, suav nrog kev ua haujlwm coding (lub coding muaj nuj nqi tuaj yeem thaiv), thiab kev ua haujlwm ntawm kev txiav tawm qhov tsis zoo K tus nqi ntawm V2 thiab tsis zoo code scanning ( tau tshaj V1 thiab V2 kev xeem), ib-nias hloov dua siab tshiab) muaj zog xws li cov ntaub ntawv losis tswvyim dabtsi thiab uploading rau lub MES system, uas yuav ua tau raws li cov kev xav tau ntawm ntau yam kev ua hauj lwm.
Khoom nta
Kab rov tav nyob deb ntawm qhov chaw sim thiab qhov chaw coding tuaj yeem hloov kho manually, thiab cov khoom sib raug zoo yog muaj zog.
Cov khoom siv ua haujlwm ua haujlwm:
Testable khoom ntau yam thiab blister tais yuav tsum:
Tsis tu ncua square hom
Cells ntev A: 50mm-130mm (tsis suav nrog sab saum toj foob)
Cells dav B: 30mm-85mm
Tab Length C: 6mm-20mm(hauv qab 8 hli, kev txiav txim tsis ncaj yuav tshwm sim)
Tab nrug D: 2.0mm saum toj no
Thickness: 3 hli -10 hli
Technical parameters:
Technical specifications ntawm txhua qhov system:
|
Yam khoom |
Cov kev xav tau |
Kev piav qhia |
|
Ceev |
18-30PPM |
Nyob ntawm lub roj teeb loj thiab tus naj npawb ntawm cov hlwb pertray, ntau lub hlwb hauv atraythe siab dua qhov ua tau zoo |
|
Thawj kis tus nqi |
Ntau dua lossis sib npaug li 99% |
Tsis suav nrog cov khoom noj tsis zoo |
|
Hwj chim |
5 kWm |
Tshuab khiav lub zog |
|
suab nrov |
Tsawg dua lossis sib npaug li 60db |
Cov ntaub ntawv ntawm ib meter deb ntawm cov khoom siv thaum lub sij hawm ruaj khov |
|
Kuaj repeatability |
Hioki 3561/BT3562 |
Voltage ntsuas ntau yam DC 20V, yam tsawg kawg nkaus daws teeb meem: 0.1mV, ntsuas qhov tseeb: ±0.01%rdg.±3dgt.(Ex.FAST xav tau ntxiv ±3dgt..,FAST/MEDIUM xav tau ntxiv 士2dgt.) Kev ntsuas qhov ntsuas kub 300mQ (ntau tshaj zaub 310.00mQ, daws teeb meem 10μQ) ~ 32 ntau yam (ntau tshaj zaub 3.10002, daws teeb meem 100μQ), 2- qib hloov Kev ntsuas qhov tseeb: ±0.5%rdg.±5dgt.(EX.FAST xav tau ntxiv 士3dgt.,FAST/MEDIUM xav tau ntxiv 土2dgt.) |
Installation ib puag ncig xav tau
|
Yam khoom |
spec |
Parameter |
|
Khoom specification |
qhov loj |
1560 * 1423 * 1770mm (L * W * H) hli; Lus Cim: Qhov loj me yog nyob rau qhov kawg tsim loj (tsis suav nrog peb-xim teeb) |
|
hnyav |
Txog 600 kg |
|
|
xim |
thoob ntiaj teb sov grey |
|
|
Ib puag ncig xav tau |
Cua |
Siab siab dua lossis sib npaug rau 6bar; (muab los ntawm cov neeg siv khoom) |
|
Lub tshuab nqus tsev |
Lub tshuab nqus tsev kawm qib siab dua lossis sib npaug rau -75KPa; (muab los ntawm cov neeg siv khoom) |
|
|
Qhov hluav taws xob |
Voltage 220V 50Hz; voltage ntau ± 10%; Hwj chim: 5KW, Yuav tsum muaj cov xaim hauv av thiab tiv thaiv theem poob |
|
|
Cov kabmob |
>300kg /㎡ |
