Khawm npib Cell Battery Tester

1.Application: Rau npib cell roj teeb kev ua tau zoo kuaj
2.Model: TOB-5V10mA
3.MOQ: 1SET
4.Shipping Chaw nres nkoj: XIAMEN
5.Product Orgin: Suav teb
7.Lub sij hawm xa tuaj: li 2 lub lis piam

Xa kev nug

Tsham tam sim no

Khoom Taw qhia

8 Channel Npib Cell Tester (0.1-10mA, mus txog 5V) nrog Laptop & Software rau Kev Tshawb Fawb

Specification

1 TOB-5V10mA npib cell tester yog yim-channel roj teeb analyzer los soj ntsuam cov npib me me uas muaj ntau yam tam sim no 0-10mah, voltage 0-5v. Txhua qhov channel ntawm lub ntsuas ntsuas muaj qhov tsis tu ncua-tam sim no thiab qhov tsis tu ncua-voltage, uas tuaj yeem tsim kho thiab tswj los ntawm khoos phis tawj software.

2 Lub tshuab ntsuas lub xov tooj ntawm tes no muab cov ntawv thov feem ntau hauv cov chaw kuaj roj teeb xws li kev tshawb fawb cov khoom siv hluav taws xob, kev ntsuas roj teeb, kev tsim cov roj teeb me me, kev ua kom muaj peev xwm, kev sim roj teeb, thiab lwm yam.

3 Lub npib cell tester yog tsim rau txhua hom npib ntawm tes roj teeb xws li lithium roj teeb, NI-MH roj teeb, Zn-Mn saib roj teeb thiab lwm yam.

Tshuab qauv	Npib Cell Tester TOB-5V10mA
Qhov chaw voltage	110v rau 220v 50/60HZ
Hwj chim	30W
Tam sim no ntau yam	0-10mA {{0}}.05%RD±0.1%FS (tswj thiab ntsuas)
Voltage ntau	0-5V {{0}}.1%RD±0.1%FS (tswj thiab ntsuas)
Lub voj voog	9 999 kwg
Cov ntsiab lus ntawm kauj ruam	Tsis tu ncua tam sim no c / d, tsis tu ncua voltage c / d, tsis tu ncua fais fab tuag, tas li tsis kam tawm, DCIR, so
Cov xwm txheej ntawm kev txwv	Lub sij hawm, voltage, tam sim no, muaj peev xwm, thiab lwm yam.20 yam
Kev tiv thaiv hom	Overvoltage, nyob rau hauv voltage, tshaj tam sim no, nyob rau hauv tam sim no, tshaj muaj peev xwm, thiab lwm yam.
Programming cov kauj ruam	Unlimited (ntau tshaj 200 kauj ruam)
Cov channel	Yim ywj pheej programmable channels Txhua tus channel tuaj yeem teeb tsa hom kev ua haujlwm sib txawv thiab ua haujlwm ntawm nws tus kheej
Tso zis hom	4 electrode (txhawb kev siv electrode test)
Software	1 Lub software nrog calibration muaj nuj nqi suav nrog los teeb tsa ntau yam haujlwm hom kev ntsuas lub peev xwm thiab lub neej voj voog rau txhua hom roj teeb rov qab 2 Hom kev ua haujlwm suav nrog kev tso tawm tsis tu ncua, tus nqi tam sim no tsis tu ncua, tsis tu ncua voltage them, so, thiab lwm yam 3 Cov xwm txheej txwv tsis pub muaj xws li voltage, tam sim no, lub sijhawm, muaj peev xwm, negative voltage nqes hav, thiab lwm yam 4 Nrog rau lub sijhawm saib xyuas qhov rais thiab cov duab sib xyaw ua ke / cov ntaub ntawv qhov rais, cov txheej txheem xeem tuaj yeem pom ncaj qha thiab ua haujlwm tau zoo 5 Lub calibration software yuav siv tau los calibrate lub analyzer
Daim ntawv ntsuam xyuas thiab nkhaus	1 Ntau hom nkhaus tuaj yeem tsim los ntawm software raws li tus neeg siv txhais. (Voltage-lub sij hawm nkhaus, tam sim no-lub sij hawm nkhaus, muaj peev xwm-voltage nkhaus, voj sij hawm-them / Tshem tawm muaj peev xwm nkhaus, voj voj voog sij hawm them / tso tawm efficiency nkhaus, thiab lwm yam) 2 Cov ntaub ntawv tshaj tawm yog tsim los ntawm software. 3 Cov neeg siv tau yooj yim piv cov kev ua tau zoo ntawm cov roj teeb uas tau sim nyob rau hauv cov channel ob qho tib si visually thiab statisticically
Dimension	250 * 200 * 60mm
Qhov hnyav	12kg ua
Kuaj clamps
Kuaj cov txiaj ntsig nkhaus
Kev teeb tsa zaub mov
