20V10A Laptop Roj teeb Tester Nrog 8 Channel

1.Model:TOB-CE-5008-20V10A-SMB
2.Specification: 20V10A
3. Channel naj npawb: 8
4.MOQ: 1set

Xa kev nug

Tsham tam sim no

Khoom Taw qhia

20V10A Laptop Battery Tester Nrog 8 Test Channel

Specification

Yam khoom	Parameter
Qhov hluav taws xob	AC220V ± 10% / 50Hz
Input zog	1800W
Kev daws teeb meem	AD: 16 ntsis; DA: 16bit
Input impedance	Ntau dua lossis sib npaug li 1MΩ
Qhov hluav taws xob	Tsis tu ncua voltage ntau tswj	Nqe: 2.5V -20V Tso zis: 2.5V-20V
	Qhov tseeb	± 0.02% ntawm FS
	Kev ruaj ntseg	± 0.01%
Tam sim no	Tam sim no ntau yam ntawm ib channel	Kev them nyiaj yug: 20mA ~ 10A Discahrge: 20mA -10A
	Qhov tseeb	± 0.03% ntawm Ntau
	Kev ruaj ntseg	± 0.015%
Hwj chim	Lub zog ib channel	200W
Hwj chim	Kev ruaj ntseg	±0.05%
Sijhawm	Tam sim no lub sij hawm teb	Tam sim no los ntawm 10%-90% lossis 90%-10%, hardware teb lub sij hawm tsawg dua los yog sib npaug li 20ms
Kauj ruam lub sij hawm	1-65535 min/pib	Kev them nyiaj yug lub sij hawm hom:00:00:00(h,min,s)
Hnub tim	Cov ntaub ntawv mob	Sijhawm ∆r:(0.01s-60000s)
		Voltage ∆U: (5mV -20V)
		Tam sim no: ∆I: (5mA-10A)
	Cov ntaub ntawv zaus	100 Hz
Kev them nyiaj	Kev them nyiaj hom	Tus nqi tam sim no, tsis tu ncua voltage, tsis tu ncua tam sim no thiab voltage, tsis tu ncua nqi zog, tas li lub zog thiab qhov hluav taws xob
Kev them nyiaj	Cov xwm txheej ntawm txwv	voltage, tam sim no, ntsig txog lub sijhawm, muaj peev xwm
Tshem tawm	Discharge hom	Kev tso tawm tsis tu ncua, tsis tu ncua lub zog tawm, tas li tam sim no thiab voltage tawm
Tshem tawm	Cov xwm txheej ntawm txwv	voltage, tam sim no, ntsig txog lub sijhawm, muaj peev xwm
Lub voj voog	Ntau yam	1~65535
	Kauj ruam ib lub voj voog	255
	Nested Loop	Kev them nyiaj yug cross-loop dhia mus rau txhua kauj ruam, max tuaj yeem txhawb nqa 4 txheej
Kev tiv thaiv	Software	Fais fab-down cov ntaub ntawv tiv thaiv, off-line xeem muaj nuj nqi thiab kev nyab xeeb xwm txheej kev tiv thaiv
Kev tiv thaiv	Kho vajtse	Ntxiv anti rov qab tiv thaiv module Offline xeem muaj nuj nqi Kev tiv thaiv kev nyab xeeb tuaj yeem ua tau tau teeb tsa: voltage sab sauv txwv, voltage qis qis, tam sim no lub limit, voltage qis qis, muaj peev xwm sab sauv txwv, ncua sij hawm
Channel yam ntxwv	l Siv cov cuab yeej siv hluav taws xob txuag hluav taws xob, lub zog ntws hauv zos ntawm cov channel, txuag hluav taws xob thiab kev tiv thaiv ib puag ncig; l Siv tsheb-theem kev tswj lub ntsiab, 200KHZ high-frequency conversion, tsis tshua muaj suab nrov; l Cov khoom siv me me, kev siv hluav taws xob tsawg, tsis muaj cua sov; l Qhov chaw tam sim no tsis tu ncua thiab qhov chaw siab tsis tu ncua txais kev ywj pheej ob chav kaw-loop qauv; l Lub kaw lus tau txais kev tsim qauv tsim, chav tsev txuas ncaj qha mus rau qhov ntsuas server hauv Is Taws Nem; l High-speed 100HZ sampling; l Ib channel 1GB ntawm offline cia muaj peev xwm
Channel tswj	Kev tswj hwm ywj pheej
Kev ntsuas hluav taws xob thiab ntsuas tam sim no	Plaub-xaim kev sib txuas
Suab nrov	<85dB
Database	MySQL Database
Ib Hom Kev Sib Txuas Lus ntawm Upper Machine	TCP/IP raws tu qauv
Cov ntaub ntawv tso zis	EXCEL, TXT, Chart
Kev sib txuas lus Interface	Ethernet 100M
Tus naj npawb ntawm cov channel tseem ceeb hauv ib chav	8
Dimension	Ib chav tsev loj: W * D * H: 500 * 480 * 186 (mm) Tshuab txee loj: W * D * H: 606 * 800 * 1800 (mm)

Cov cuab yeej ua haujlwm ib puag ncig

Qhov project index	Parameter index
Ua hauj lwm kub ntau yam	25 degree ± 10 degree
Cia qhov kub thiab txias	0 degree ~ 45 degree
Ua hauj lwm ib puag ncig txheeb ze humidity Range	30% -80% RH (Tsis muaj dej vapor)
Cia ib puag ncig txheeb ze humidity Range	30% -90% RH (Tsis muaj dej vapor)
