Three Heating Zones Tube Furnace
Three Heating Zones Tube Furnace

Peb Cov Cuab Yeej Siv Hluav Taws Xob Hluav Taws Xob

Model: TOB-G1100-250-III
Max kub: 1100 degree
Lub sijhawm ua haujlwm kub: Tsawg dua lossis sib npaug li 1000 degree

Xa kev nug

Tsham tam sim no

Khoom Taw qhia

Peb Cov Cuab Yeej Siv Hluav Taws Xob Hluav Taws Xob

Specification

Daim ntawv thov

Ceramics, metallurgy, electronics, iav, tshuaj lom neeg kev lag luam, machinery, refractories, tshwj xeeb cov ntaub ntawv, tsev cov ntaub ntawv, universities, scientific research institutes, industrial thiab mining enterprises rau hmoov roasting, ceramic sintering, high-temperature sim, khoom kho mob, high-temperature cua sintering, ceramic kua nplaum tawm, flue gas kho, annealing thiab sintering, thiab lwm yam.

Lub tshuab hluav taws xob siv lub tshuab hluav taws xob ua hluav taws xob ua hluav taws xob, siv lub plhaub ob txheej txheej thiab 30 ntu kev tswj hwm qhov kub thiab txias, theem hloov pauv thiab thyristor tswj. Lub tshuab hluav taws xob txais cov khoom lag luam siab purity alumina fiber ntau, lub tshuab nqus tsev tsim fiber ntau thiab cov khoom siv lub teeb. Ob chav furnace qauv yog saws. Lub tshuab hluav taws xob muaj qhov zoo ntawm qhov sib npaug ntawm qhov kub thiab txias, qhov kub thiab txias, qhov kub ceev thiab qhov poob qis, lub zog txuag thiab lwm yam.

Nws txais kev siv thev naus laus zis thoob ntiaj teb, nws tus kheej tsim hom tshiab nrog kev ua haujlwm siab thiab kev txuag hluav taws xob, thiab siv cov khoom siv hluav taws xob txuag hluav taws xob ob txheej txheej, uas tuaj yeem txo qhov kub ntawm sab nraud mus rau qhov kub thiab txias thiab ua rau qhov kub thiab txias hauv cov kab noj hniav. tsis sib xws.

Qauv	TOB-G1100-250-III
Qhov hluav taws xob	AC 220V 50HZ (Customized rau 60HZ)
Lub zog cua sov	15 KW
Rauv tube loj	250 * 1800mm (Txoj kab uas hla * Length)
Rauv tube khoom	High purity calcined quartz raj
Qhov chaw cua sov	Peb Cheeb Tsam: 250mm * 1200mm
Qhov ntsuas kub tsis tu ncua	250mm * 800 hli
Ua haujlwm kub siab tshaj plaws	1100 degree
Lub sij hawm ua haujlwm kub	1000 degree
Cua sov ntsiab	Imported Kangtaier kuj hlau Tag nrho cov txheej txheem cua sov. (Resistance wire, nrog rau ib cheeb tsam ntawm sab saum toj thiab hauv qab, cua sov ntev li ntawm 500mm ib cheeb tsam, qhov kub thiab txias qhov sib txawv ± 5 degree (tuav rau 30 feeb yam tsis muaj load nyob rau hauv qhov kub thiab txias cheeb tsam)
Cua sov tus nqi	1-20 degree / min, kho tau
Pom zoo cua sov tus nqi	3-8 degree / min
Tswj qhov tseeb	± 1 degree
Huab cua	Oxygen, Nitrogen, Argon thiab lwm yam huab cua
Qhov ntsuas kub ntsuas qhov ntsuas thiab ntsuas qhov ntsuas kub	K thermocouple, ntsuas qhov ntsuas kub ntau 0-1200 degree . Lub thermocouple yog nyob ze rau (sib cuag) cov phab ntsa sab nrauv ntawm lub raj, uas tuaj yeem txo qhov kub ntawm sab nraud mus rau qhov kub thiab txias thiab ua rau qhov kub thiab txias faib rau hauv cov kab noj hniav sab hauv.
Cov khoom siv hluav taws xob	Chint lossis Schneider hom
Instrument tswj	YudianGP518P
Sealing Cheebtsam	Flange
Lub tshuab nqus tsev	Lub tshuab nqus tsev qis 200-2000pa
Flowmeter (yeem)	50-500ml/min
Tswj hom	Tswj hom: tag nrho tsis siv neeg tswj qhov system, uas tuaj yeem khiav tau los ntawm chav tsev kub rau qhov kub thiab txias. Lub kaw lus yog tswj los ntawm thyristor, thiab kev tswj qhov kub thiab txias yog modularized, nrog cov qauv yooj yim thiab kev saib xyuas yooj yim. Nws txais cov cuab yeej Yudian, kev tswj hwm thyristor txawv teb chaws, programmable 30 ntu, ntau ntu hluav taws xob limiting muaj nuj nqi, ntau pab pawg PID parameter nws tus kheej-tuning muaj nuj nqi, pub dawb ntawm qhov ntsuas kub tsis tu ncua thiab rwb thaiv tsev nkhaus, tsis cuam tshuam kev hloov pauv, thiab cov cuab yeej muaj nuj nqi ntawm kev kho qhov kub thiab txias.
Tus naj npawb ntawm programmed nkhaus ntu	30 ntu yog kho tau, uas tuaj yeem txo qhov teeb meem tsis tsim nyog los ntawm kev teeb tsa.
Digital zaub	Muab ob npaug rau qhov ntsuas kub thiab qhov ntsuas kub. Cua sov fais fab kab zaub
Qhia qhov tseeb	± 1 degree
Rauv layout
Tswj yam ntxwv	Modular qauv ntawm kev tswj qhov system, lub neej ntev tsim ntawm cov khoom tseem ceeb ntawm cov khoom, cov txheej txheem yooj yim thiab txhim khu kev qha, zoo stability thiab siab precision.
Cua txias system	Lub kiv cua impeller yog ntsia ncaj qha rau hauv qab ntawm ob txheej txheej rauv lub plhaub thiab sib sau ua ke nrog kev tswj hwm. Thaum lub cub tawg yog cua sov, cua txias tuaj yeem txo qhov kub ntawm lub plhaub ntawm lub cub tawg thiab tiv thaiv cov cua kub dissipation ntawm cov khoom siv hluav taws xob, ua rau cov neeg ua haujlwm muaj kev nyab xeeb thiab txhim kho kev ua haujlwm.
Cov khoom siv refractory	Lub tshuab hluav taws xob hauv ob sab phlu txais cov khoom siv high-purity alumina fiber ntau, lub tshuab nqus tsev tsim fiber ntau thiab lub teeb hollow aluminium oxide phaj. Nws muaj qhov kub thiab txias, me me khaws cia muaj peev xwm, kub ceev thiab txias tsis kam, tsis muaj tawg, tsis muaj slag ntog thiab zoo thermal rwb thaiv tsev kev ua tau zoo (lub zog-txuag nyhuv yog ntau tshaj 80% ntawm cov qub hluav taws xob cub hluav taws xob). Ob chav rauv qauv, uas tsis tsuas yog muaj cua sov ceev, tab sis kuj muaj cov yam ntxwv ntawm lub zog thiab ruaj khov, thiab tsis muaj kev sib tsoo hauv kev siv mus ntev. $Refractory material$
Cov khoom siv thermal rwb thaiv tsev	Imported alumina multi fiber rwb thaiv tsev cov ntaub ntawv, lub rwb thaiv tsev txheej yog 120mm.
Plhaub	Nws yog welded los ntawm steel phaj thiab profile, thiab lub plhaub yog nruab nrog detachable tiv thaiv phaj, uas siv electrostatic txau thiab xim ci. Fine workmanship thiab elegant tsos.
Rauv qauv	Muab ob npaug rau txheej rauv plhaub qauv, cua txias ncig, txo lub plhaub kub, thiab lub plhaub saum npoo kub yog tsawg dua 55 degree. Qhov saum npoo ntawm lub qhov cub sab hauv yog coated nrog high-temperature alumina txheej, uas tuaj yeem txhim kho cov cua sov ntawm cov khoom siv thiab ua kom lub neej ntev ntawm cov cuab yeej siv. Qhov qhib nruab nrab ntawm lub qhov rooj rauv thiab lub qhov cub lub cev yog kev ruaj ntseg los ntawm stainless hlau xauv nplhaib txuas nrog hinges.
Qhov cub qauv feature	Lub qhov cub lub cev yog cua sov rau tag nrho plaub sab, nrog rau cov cua sov, thermocouples, thiab controllers. Ib feem ntawm cov khoom siv rauv yog tsim los ntawm cov ntaub ntawv fiber ntau ceramic thiab hollow spherical alumina. Sab saum toj ntawm lub cub tawg yog lub qhov cub mesh npog, thiab cov pa roj carbon steel phaj nyob rau sab ntawm lub qhov cub lub cev yog 3 hli. Txhawm rau tiv thaiv kom tsis txhob muaj cua sov hauv daim ntawv ntawm cov hluav taws xob thermal, ob chav rauv qhov rooj ntsaws ruaj ruaj yog siv.
Kev txuag hluav taws xob	Lub teeb yuag, kub ceev ceev, txuag hluav taws xob ntau dua 50%, txuag lub sijhawm thiab kev ua haujlwm txuag.
Cov khoom seem	Ib phau ntawv, ib lub Crucible tongs, ib nkawm hnab looj tes kub.
