1100 Degree Muffle Rauv

Model: TOB-X1100-30S
Max kub: 1100 degree
Lub sijhawm ua haujlwm kub: Tsawg dua lossis sib npaug li 1000 degree

Xa kev nug

Tsham tam sim no

Khoom Taw qhia

Laboratory1100 Degree Muffle Rauv

Specification

Kev siv tseem ceeb: ceramics, metallurgy, electronics, iav, tshuaj, machinery, refractory cov ntaub ntawv, tshwj xeeb cov ntaub ntawv, tsev cov ntaub ntawv, universities, scientific research institutes, industrial thiab mining enterprises rau hmoov roasting, ceramic sintering, siab kub thwmsim, khoom ua, zoo universities , scientific research institutes, Industrial and mining enterprises do high-temperature sintering, cua txo, CVD xyaum, nqus annealing, thiab lwm yam.

Lub tshuab hluav taws xob no siv cov silicon carbide rods ua cov khoom cua sov, txais yuav ob txheej txheej plhaub thiab ib qho 31- ntu kev tswj qhov kub thiab txias, theem hloov pauv, thiab thyristor tswj. Lub tshuab hluav taws xob siv tag nrho cov khoom siv high-purity alumina fibers thiab lub tshuab nqus tsev fiber ntau poly lub teeb board. khoom. Nws adopts ob chav hearth qauv. Lub tshuab hluav taws xob muaj qhov zoo ntawm qhov sib npaug ntawm qhov ntsuas kub, qhov kub tsis tshua muaj qhov kub, qhov kub thiab txias ceev ceev, thiab txuag hluav taws xob.

Txais siv cov cuab yeej siv thoob ntiaj teb, kev tsim tus kheej ua haujlwm siab, txuag hluav taws xob tshiab, siv lub zog txuag hluav taws xob cov khoom siv hluav taws xob ob txheej txheej, tuaj yeem txo qhov kub ntawm sab nraud kom sov li qub thiab ua rau cov kab noj hniav kub tsis sib xws.

Yam khoom	TOB-X1100-30S
Voltage AC	220 V
cua sov zog	3 KW
Qhov cub chamber loj (mm)	300 x 200 x 120 mm
Ua haujlwm kub siab tshaj plaws	1100 degree
Lub sijhawm ua haujlwm kub	Tsawg dua lossis sib npaug li 1000 degree
cov khoom cua sov	Ni-Cr alloy hlau
Cua sov tus nqi	1-20 degree / min Kho tau
Pom zoo cua sov tus nqi	5-8 degree / min Kub nce tus nqi
Kub tswj qhov tseeb	± 1 degree
Qhov ntsuas kub ntsuas qhov ntsuas thiab ntsuas qhov ntsuas kub	K thermocouple, Qhov ntsuas kub ntawm qhov ntsuas kub yog 0-1200 degree , thiab cov thermocouple nyob ze rau ib leeg, uas tuaj yeem txo qhov kub ntawm qhov kub thiab txias thiab ua kom qhov kub thiab txias hauv cov kab noj hniav sib xws.
Cov khoom siv hluav taws xob qub	Ib nrab xaiv ntawm Schneider imported hom
Instrument tswj	Yudian GP518P
Tswj cov txheej txheem	Kev tswj txoj kev: txais kev tswj hwm tsis siv neeg tag nrho, uas tuaj yeem ua haujlwm tau tom qab teeb tsa qhov kev pab cuam los ntawm chav tsev kub kom sov. Lub kaw lus tuaj yeem tswj tau los ntawm thyristor, thiab kev tswj qhov kub thiab txias muaj cov qauv tsim, qauv yooj yim thiab kev saib xyuas yooj yim. Txais Yudian ntsuas, imported thyristor tswj, programmable 31 ntu, ntau ntu fais fab kev txwv muaj nuj nqi, ntau pawg PID parameter nws tus kheej-tuning muaj nuj nqi, dawb do teeb qhov kub thiab txias khaws cia nkhaus, tsis cuam tshuam kev hloov pauv muaj nuj nqi, ntsuas kub kho thiab them nyiaj Nta.
Programming nkhaus ntu ntu	31 ntu yog kho tau, uas tuaj yeem txo qhov teeb meem tsis tsim nyog los ntawm kev teeb tsa kev tuav.
Qhia qhov tseeb	± 1 degree
Digital zaub	Ntsuas kub, teeb kub dual zaub
Tswj yam ntxwv	Cov kev tswj hwm muaj cov qauv qauv, lub neej ntev tsim rau cov khoom tseem ceeb ntawm cov khoom siv, cov txheej txheem yooj yim thiab txhim khu kev qha, zoo stability thiab siab precision.
Cua txias system	Lub kiv cua impeller yog ntsia ncaj qha rau hauv qab ntawm ob txheej txheej rauv lub plhaub thiab sib sau ua ke nrog kev tswj hwm. Cua txias yog ua thaum lub sintering rauv yog rhuab, uas yuav txo tau qhov kub thiab txias ntawm lub cub tawg plhaub thiab tiv thaiv lub tshav kub dissipation ntawm cov khoom siv hluav taws xob, ua hauj lwm zoo rau cov neeg ua hauj lwm thiab kev txhim kho efficiency.
Refractory	Lub tshuab hluav taws xob yog ua los ntawm cov khoom siv high-purity alumina fiber ntau, lub tshuab nqus tsev tsim fiber ntau poly lub teeb lub rooj tsavxwm, lub teeb hollow spherical alumina board, siab kub, tsis tshua muaj cua sov cia, tiv taus kub ceev thiab txias, tsis muaj kab nrib pleb, tsis muaj slag, thiab zoo thaum tshav kub kub preservation. kev ua tau zoo (Cov nyhuv txuag hluav taws xob ntau dua 80% ntawm lub qhov cub hluav taws xob qub). Lub patented ob chav rauv qauv tsis tsuas yog muaj cua sov ceev, tab sis kuj muaj cov yam ntxwv patented uas muaj zog thiab ruaj khov, thiab yuav tsis tawg tom qab siv mus ntev.
Cov khoom siv rwb thaiv tsev	Imported alumina multi-fiber rwb thaiv tsev cov ntaub ntawv, lub rwb thaiv tsev txheej yog 150mm.
Plhaub	Lub tshuab ua kom sov lub cev thiab lub plhaub ntawm lub cub tawg yog welded los ntawm steel daim hlau thiab profiles, thiab lub plhaub yog nruab nrog tshem tawm cov ntawv tiv thaiv, uas yog electrostatic txau thiab pleev xim rau. Kev ua haujlwm zoo, zoo nkauj thiab dav dav.
Rauv qauv	Muab ob npaug rau txheej rauv plhaub qauv, cua txias ncig, qis plhaub kub. Plhaub qhov kub thiab txias<60 degrees Qhov saum npoo ntawm lub qhov cub sab hauv yog coated nrog high-temperature alumina txheej los txhim kho cov cua kub efficiency ntawm cov cuab yeej thiab kuj txuas rau lub neej kev pab cuam ntawm lub ntsuas.
Kev txuag hluav taws xob	Lub teeb yuag, cua sov ceev, txuag hluav taws xob ntau dua 50%, txuag lub sijhawm thiab kev siv zog.
spare qhov chaw nrog cov khoom siv	Ib phau ntawv, ib daim ntawv pov thawj, ib tug crucible tongs, ib nkawm hnab looj tes kub
