Polymer Battery Spot Welder



Lithium Polymer Battery Tab thiab 10-120 Layers Foil Spot Welding Vuam Tshuab









Qauv	TOB-USW-8000W
Hwj chim	8000W
Ntau zaus	20 KHz
Fais fab mov	220V / 50Hz
Gas muab	Ntau dua lossis sib npaug rau 0.5MPa
Tswj txoj kev	CPU
Siab kawg stroke	20 mm
Lub sijhawm vuam	0.05-9S
Cov khoom tseem ceeb	1. Ceramic ntawv: German imported dub zaj duab xis 2. Aluminium pas nrig: American Aluminium Corporation 3. Lub taub hau vuam: hmoov hlau

Vuam muaj peev xwm	①10 ~ 120 txheej txhuas ntawv ci + 0 2-0.6 hli ntshiab txhuas tab welding, vuam chaw 4 * 6 / 4 * 8 / 4 * 10mm / 5 * 30mm
	②10 ~ 120 txheej tooj liab ntawv nyiaj + 0.
	③0.
	④0 2-0.6 hli txhuas tab, tuaj yeem welding nrog 10 ~ 90 txheej ntawm aluminium ntawv ci, Vuam qhov chaw 4 * 6,4 * 8,4 * 10mm
	⑤0.
	⑥{0} 2-0.6 hli txhuas sawb thiab 2.0 hli txhuas phaj vuam



Muaj nuj nqi Taw qhia

1.1 Controller: Lub Circuit Court txais thoob ntiaj teb siab tshaj plaws-bridge voltage regulator Circuit Court thiab yog optimized kom tiav amplitude tso zis tas li thiab tsis siv neeg zaus mus txog qhovtwg yam tsis muaj phau ntawv hloov. Txais kev tswj hwm kev txawj ntse, npog hom xws li lub sijhawm, lub zog, lub zog, lub zog thiab qhov tob.

1.2 lub taub hau vuam yog ua los ntawm cov hmoov hlau tuaj txawv teb chaws, siab hardness, cov qauv yog ua los ntawm kev sib tsoo siab, kev pab lub neej ntev heev, 13-15 lab zaug ntawm ib sab.

1.3 ultrasonic nyob rau hauv lub suab ncej, nruj xaiv ntawm txawv txawv pwm steel, hnav tsis kam, kub tsis kam, zoo toughness, siab mechanical rigidity, me me deformation tom qab tshav kub kho, yog li cov ultrasonic tso zis zaus sib xws yog siab, cov neeg kho tshuab siab zaus hloov amplitude yog loj, muaj zog, ruaj khov.

1.4 welding nyhuv: vuam yog ruaj, tsis tshua muaj nyob rau hauv tsis kam, tsis muaj soldering, tsis muaj vibration hmoov, tsis muaj burning diaphragm, tsis kub insulating roj hmab, tsis muaj cracking ncej, qhov seem welding nto ntawm hlau thiab hlau yog ntau tshaj 80%. Qhov saum npoo tom qab vuam yog tiaj, tsis muaj wrinkles, tsis muaj burrs nyob rau tom qab, cov pob qij txha yog tag nrho thiab meej, ruaj thiab txhim khu kev qha, cov pob qij txha tsis tawg, thiab lub zog tensile tuaj yeem kuaj raws li cov txheej txheem sib txawv thiab cov khoom siv.

1. lub sij hawm tso saib zaus thiab vuam fais fab kom ntseeg tau tias vuam nyhuv, txhaum hom tswb, thiab lwm yam.

1.6 khau raj tsis siv neeg tshawb nrhiav muaj nuj nqi: tus welder muaj lub hwj chim-ntawm tus kheej-kawg kuaj muaj nuj nqi, luam theej duab vuam qhov ntsuas tsis tau thiab tso saib hauv lub sijhawm, yog tias muaj teeb meem, teeb tsa lub tswb kom tsis txhob ua haujlwm raws li kev ua txhaum cai.

1.7 Welding zoo cov ntaub ntawv auxiliary muaj nuj nqi: Raws li lub sij hawm lub sij hawm vuam cov ntaub ntawv tsis, lub sab sauv thiab sab amplitudes ntawm vuam tsis yuav tsum tau teem rau saib xyuas qhov zoo ntawm txhua vuam khoom, thiab lub sab sauv thiab sab amplitudes yog biased, thiab cov khoom siv. yuav tswb.

1.8 Amplitude tsis siv neeg them nyiaj ua haujlwm: Lub tshuab vuam muaj qhov tsis siv neeg amplitude them nyiaj ua haujlwm, uas tuaj yeem hloov kho qhov amplitude tso zis kom lub amplitude tso zis ntau ruaj khov, txhim kho vuam stability thiab xyuas kom meej qhov sib xws ntawm vuam zoo.
