20kHz Ultrasonic Hlau Vuam Tshuab

Qauv: TOB-20K-1500W
TOB-20K-1500W digital ultrasonic vuam system nrog German transducer, nws pib zaus nrhiav, thiab ntau hom kev tswj. Tsim los rau lithium-ion roj teeb tab, hnab cell, thiab cov ntawv hlau hlau txuas.

Xa kev nug

Tsham tam sim no

Khoom Taw qhia

Xiamen TOB Tshiab Zog Technology Co., Ltd. yog ib qho ntawm feem txhim khu kev qha manufacturers thiab lwm tus neeg ntawm 20khz ultrasonic hlau vuam tshuab nyob rau hauv Suav teb. Txais tos kom yuav zoo 20khz ultrasonic hlau vuam tshuab ntawm tus nqi sib tw los ntawm peb lub hoobkas. Yog tias koj muaj lus nug txog kev koom tes, thov koj xav email rau peb.

20kHz Ultrasonic Hlau Vuam Tshuab

Product Video

Specification

Kev Taw Qhia luv luv ntawm TOB-20K Series Generator

1.Lub 20K ntse series txais siab -kev ua tau zoo los tiv thaiv- cuam tshuam microprocessors kom ua tiav kev tswj hluav taws xob. Tag nrho cov kev tswj tsis tau vuam yog tswj los ntawm microcomputers, thiab lub ntse zaus tswj qhov system tshem tawm qhov tsis yooj yim ntawm kev tswj hwm zaus. Lub suab overload raug kuaj pom, thiab qhov zoo tshaj plaws resonance point yog taug qab nyob rau lub sijhawm. Qhov kub ntawm cov pab pawg vibration tseem nyob ntawm nws qhov qis tshaj plaws, thiab qhov kub ntawm lub vuam taub hau ua raws li qhov kev hloov pauv ntau zaus. Lub tshuab tau hloov kho thiab ua haujlwm ruaj khov dua.

2.Thaum ultrasound ua rau ntawm qhov chaw sib cuag hlau, nws yuav tsim ntau txhiab tus siab - zaus vibrations ib ob. Qhov siab no - zaus vibration, uas ncav cuag ib qho amplitude, xa ultrasonic zog mus rau qhov chaw vuam los ntawm lub vuam qaum. Vim lub suab nrov tsis kam ntawm qhov sib cuam tshuam ntawm ob qhov chaw vuam, qhov kub thiab txias hauv zos yuav raug tsim. Vim yog qhov tsis zoo thermal conductivity ntawm cov hlau, nws tsis tuaj yeem dissipate raws sij hawm thiab accumulates nyob rau hauv lub vuam cheeb tsam, ua rau qhov sib cuag ntawm ob hlau sai sai yaj. Tom qab ntxiv ib tug npaum li cas ntawm lub siab, nws merges rau hauv ib tug. Tom qab lub ultrasound tsis ua haujlwm, cia lub siab txuas ntxiv rau ob peb feeb kom khov thiab tsim cov saw hlau molecular, ua tiav lub hom phiaj ntawm vuam. Lub zog vuam tuaj yeem nyob ze rau lub zog ntawm cov khoom siv raw. Qhov zoo ntawm ultrasonic hlau vuam nyob ntawm peb yam: lub amplitude ntawm lub transducer lub vuam taub hau, lub siab thov, thiab lub sij hawm vuam. Lub sijhawm vuam thiab vuam lub taub hau siab tuaj yeem hloov kho, thiab qhov amplitude yog txiav txim siab los ntawm lub transducer thiab lub amplitude lever. Nws muaj qhov tsim nyog rau kev sib cuam tshuam ntawm peb qhov ntau. Thaum lub zog ntau tshaj qhov tsim nyog, qhov melting ntawm cov hlau yog ntau dua thiab vuam tsis tshua muaj deformation. Yog tias lub zog me me, nws tsis yooj yim rau welding kom ruaj khov, thiab lub siab thov yuav tsum tsis txhob siab dhau. Qhov siab tshaj plaws yog 1mm mus rau 5mm hauv qab ntawm ntug ntawm qhov vuam seem.

Daim ntawv thov Scope ntawm Ultrasonic Vuam Tshuab

Copper raj sealing thiab txiav
Automotive kab hlau rhuav
Solar vaj huam sib luag welding
Vuam ntawm tooj liab, aluminium thiab lwm yam hlau
Multi- taw tes vuam ntawm roj teeb cathode aluminium strip
Ib qho - taw tes vuam ntawm roj teeb lub hau thiab txhuas sawb
Vuam ntawm cathode thiab anode electrodes ntawm 18650 hnab cell
Hauv qab ntawm lub roj teeb aluminium plhaub yog welded nrog aluminium -nickel composite daim kab xev
Hnub ci vuam ntawm iav phaj
Hnab cell multilayer lamination welding
Square npauj npaim welding
Hnab cell aluminium rau nickel

Cov yam ntxwv ua haujlwm

Tag nrho cov ultrasonic system tuaj ntawm lub teb chaws Yelemees.
Lub ascending thiab descending ceev ntawm vuam taub hau tuaj yeem hloov kho thiab tswj kom raug.
Nws tuaj yeem txheeb xyuas qhov chaw sab sauv thiab qis ntawm cov qauv welded.
Thaum qhov hluav taws xob hloov pauv, lub tshuab hluav taws xob ultrasonic tuaj yeem them nyiaj rau qhov tso zis hluav taws xob kom ntseeg tau tias cov zis ruaj khov ntawm lub vuam taub hau amplitude.
Kev tswj xyuas lub zog kom raug tuaj yeem ua kom muaj kev ruaj ntseg ntawm txhua qhov vuam thiab txo qhov cuam tshuam ntawm lwm yam.
Cov cuab yeej siv lub taub hau vuam siv tsis siv neeg zaus taug qab yam tsis muaj kev hloov kho zaus. System self-test, tsis muaj zaus hloov. Tom qab lub vuam taub hau hloov lossis kho, lub kaw lus tsis tas yuav tsum tau hloov kho (qee cov qauv yuav tsum tau tshawb xyuas qhov zaus ntawm lub tshuab hluav taws xob).
Daim ntawv thov ntawm IGBT fais fab module thiab cov qauv ntawm cais zoo siab oscillation circuit.
Thaum ua hauj lwm, qhov zaus ntawm vuam lub taub hau thiab transducer yuav hloov nrog kev hloov ntawm qhov kub thiab txias, thiab lub vuam tshuab tuaj yeem tshawb nrhiav thiab taug qab cov zaus resonant ntawm cov transducer tag nrho, txhawm rau xyuas kom meej tias cov transducer ib txwm ua haujlwm hauv lub xeev resonant, xyuas kom cov khoom siv tau zoo, thiab ua kom vuam ntau ruaj khov thiab txhim khu kev qha.
Cov qauv vuam nrog ntau hom vuam xws li lub zog thiab lub sijhawm ntse tuaj yeem hloov kho rau cov txheej txheem vuam sib txawv thiab ua tiav cov txiaj ntsig zoo dua vuam.
Lub amplitude ntawm 1% -100% tuaj yeem teem caij rau lub sijhawm ntawm 0-100ms, uas yog qhov zoo dua rau cov txheej txheem vuam sib txawv.
Customizable huab kev pabcuam. Kev txawj ntse tiv thaiv tshuab thiab ua txhaum lub tswb ceeb toom.
Kev tiv thaiv hluav taws xob (qhov ntau ntawm cov khoom siv hluav taws xob yog 215 V ~ 238 V); Lub zog tso zis thiab ua haujlwm zaus ntawm lub tshuab no yuav tsis cuam tshuam rau lub sijhawm tsis siv neeg qhov hluav taws xob tas li;
Overload tiv thaiv system; (3) tiv thaiv overcurrent; (4) tsis siv neeg them nyiaj rau lub zog tsis ruaj khov; (5) welding overload tiv thaiv teeb liab tawm tswv yim.
Tag nrho cov ntsuas ntsuas ntawm cov cuab yeej siv metric units.
Siab -tus txiv neej txhais lus- tshuab pauv kov npo thiab cov ntawv qhia kev ua haujlwm zoo.
Ntau tshaj 100 cov ntaub ntawv vuam tuaj yeem kuaj xyuas.

Technical Parameters

Yam khoom	Technical parameters
1. Cov khoom siv hauv paus
1.1 Cathode
1.1.1 Cov khoom siv substrate	Al fiol
1.1.2 Substrate khoom thickness	0.012
1.1.3 Tab material	Al tab
1.1.4 Wire rod	0.2-0.5
1.2 Anode
1.2.1 Cov khoom siv substrate	Cu foil
1.2.2 Substrate khoom	0.08-0.012
1.2.3 Tab material	Nickel plated tooj liab / npib tsib xee tab
1.2.4 Tab thickness	0.2-0.4

2.Xov
2.1 Laminating txheej txheem
2.2 Cov txheej txheem laminated ntau tshaj (kev lees paub)	10-45 txheej (nyob ntawm qhov ntev ntawm vuam)
2.3 Cell thickness

3. Tab welding
3.1 Vuam hom ntawm tab	Crosswise (customizable)
3.2 Vuam muaj peev xwm ntawm tab	Txheej los ntawm txheej vuam, tsis muaj blackening.
3.3 Vuam qhov ntev	20MM (Customizable)
3.4 Vuam qhov dav	3MM (Customizable)
3.5 Vuam lub sijhawm	Hauv 1S
3.6 Tus naj npawb ntawm cov chaw vuam	Tsim raws li txheej txheem vuam.
3.7 Lub sijhawm hloov kho ntau yam	0-60S, kho tau
3.8 Vuam nto lub neej	Ntau dua lossis sib npaug li 100,000 npaug

4. Weld taub hau txheem
4.1 Weld taub hau khoom	Imported siab ceev steel
4.2 Welding qhov siab	0.8mm (nyob ntawm cov khoom sib txawv, cov khoom siv tshuab yuav tsum tau muab)
4.3 Welding chaw/grain distribution state	Cov kab ncaj nraim lossis * kab ntawm lub taub hau vuam sab saud; Lower tuag reticulate qauv
4.4 Qhov siab ntawm vuam nto los ntawm vuam taub hau	＞ 5mm (hloov raws li cov khoom siab)
4.5 Ntev ntawm vuam taub hau	Ntau dua lossis sib npaug li 130mm
4.6 Muaj welding nto ntawm vuam taub hau	2
4.7 Vuam taub hau installation kev taw qhia	Crosswise
4.8 Amplitude adjustable ntau yam	Ib nrab voj voog 20 ~ 40um
5. Transducer
5.1 Qhov sib txawv ntawm cov transducers	Tsawg dua lossis sib npaug li 400Hz
5.2 impedance sib txawv ntawm transducers	Tsawg dua lossis sib npaug li 4Ω
5.3 Capacitance sib txawv ntawm transducers	Tsawg dua lossis sib npaug li 400PF
5.4 Rwb thaiv tsev tsis kam ntawm transducer thiab plhaub	Ntau dua lossis sib npaug li 30MΩ

6.Supersonic generator
6.1 Zaus tswj hom	Ua - nyob rau hauv zaus adjustable
6.2 Tsis tu ncua amplitude muaj nuj nqi	(Ntawv amplitude)
6.3 Stepless adjustable amplitude	Stepless adjustable

7. khoom
7.1 Kev tshwm sim	Tsis muaj vuam nkag los yog to, ruaj vuam thiab txheej - los ntawm - txheej nkag.
8. Tsim kev pab cuam lub neej ntawm cov khoom siv	8 ~ 10 xyoo

Khoom Parameters

Yam khoom	20KHz Ultrasonic vuam tshuab
Muab hluav taws xob	50,60Hz - / AC220V
Screen	Kov npo
Digital system	Siab ruaj khov
Ntau zaus	Tsis siv neeg taug qab
Hwj chim	1500W
Parameter txuag muaj nuj nqi	Nrog
Vuam parameter hloov tau tuaj yeem hloov kho.	Nrog
Sectional zog tswj	Nrog
Weld lub sijhawm	Yeem (0.01s-2s)
Vuam hom	Ib -point
Nyem lub sijhawm	Yeem (0.02s-10s)
Tso saib ntau qhov kev tshawb nrhiav los ntawm kev suav zaus	19.0000-21.0000HZ
adjustable zog	1000W.1500W,
Vuam hom	xaiv tau
Kev hloov kho amplitude	Amplitude stepless tswj
Txee kev tiv thaiv	Kev tiv thaiv ntse thiab kev ua txhaum lub tswb ceeb toom
Tsis siv neeg zaus taug qab	Ntau yam ± 20HZ
Tsis siv neeg ntsuas kub ntsuas	60℃tsis siv neeg tiv thaiv lub zog sab hauv lub raj
EMI/EMC	Muaj zog tiv thaiv - muaj peev xwm cuam tshuam
Cov pa roj nkag	Cua compressed gas 7-8BAT (kg / cm2)
Ua haujlwm siab tshaj plaws	6kg / cm2
Yam tsawg kawg nkaus ua haujlwm siab	0.3kg / cm2
Cua inlet sib koom	Quick sib koom 8mm
Lub tog raj kheej txoj kab uas hla	63mm ua
Lub tog raj kheej stroke	20 hli
