Kub Cycling Kuaj Chamber

1.product lub npe

1.1 Npe

1.2 qauv

Kub Cycling Kuaj Chamber

Tob-ks 5-150 c

2. Daim ntawv thov & txwv

2.1 Daim Ntawv Thov

Mas siv rau cov khoom lag luam ntawm tes thiab cov khoom siv hluav taws xob, cov khoom siv kub tsis tshua muaj cua txias, ntsuas kub hloov thiab lwm yam Simulate Kev Ntsuas Kom Muaj Kev Cog Lus.

3. Ntim & Dimension

3.1 Ntim

150L

3.2 sab hauv

W500 hli * H600 hli * D500 hli

3.3 Zuag Tag Nrho

W750mm * H1780mm * D1500mm

Cov lus Kindly: qhia meej tag nrho Pls xa mus rau qhov kawg tsim kev kos duab!

4. Kev ua tau zoo

4.1 Mob

Cua Txias Hom Nyob Hauv Ib puag ncig Patrep. +5} {1% .no load (tsis muaj ib qho hnoos qeev (tsis muaj cov quav)

4.2 TEM. Tej roob

{{0 {}} degree ~ +150 degree

4.3 Temp. Kev ywj faj ywj fwm

0. 5 degree

4.4 Temp. Kev plam kev

Tsawg dua los yog sib npaug ± 2 degree

4.5 temp. Grongent

Tsawg dua los yog sib npaug ± 2. 0 degree

4.6 temp. Cua sov lub sijhawm

Los ntawm -40 degree rau 85 degree, tag nrho ntau qhov nruab nrab tsis-linear nruab nrab txog5 degree \/ mins, tsis muaj nra

4.7 temp. Lub sijhawm txias

Los ntawm 85 degree rau -40 degree, tag nrho ntau qhov chaw tsis-linear \/ mins, tsis muaj nra

4.8 temp. Rau overshoot

Tsawg dua los yog sib npaug ± 2 degree

4.9 suab nrov

Tsawg dua los yog sib npaug rau 70db (qib)

4.10 Nyhav

Kwv yees li 600kg

4.11 Fais Fab

380v, 50Hz, peb theem, 9kW

4.12 qauv ua tiav

Iec {62133-2012- Tshooj 7.2.4 Cua sov cycling

UL 1642- Tshooj 18 Qhov Kub Cycling

Un38.3 Xeem T.2: Kev Kuaj Hluav Taws Xob

Iec {60068-2-1}: Kev sim ib puag ncig ib puag ncig - Tshooj 2: Kev Ntsuas Cov Qauv - Testions A: Txias

Iec {60068-2-2: Kev sim ua hluav taws xob ib puag ncig rau cov khoom lag luam hluav taws xob thiab hluav taws xob hluav taws xob kev ntsuam xyuas - kev ntsuam xyuas b: qhuav tshav kub

5. Txheej Txheem & Khoom Siv

5.1 Chamber Sab Nrauv

Khaub ncaws khaub thuas-yob nrog kev pleev xim.

5.2Mernernal Chamber

1. {{0 hli sus # 304 stainless hlau.

Hauv qab: 2mm tuab # 304 stainless hlau,

5.3 cov ntaub ntawv rwb thaiv tsev

100 hli pu polyurethane ua npuas dej rwb thaiv tsev khoom siv

5.4 Chamber Qhov Rooj

Ib Rooj Qhib Ib Leeg

5.5 Kev Soj Ntsuam Qhov rai

Lub Tshuab Nqus Tsev Saib Xyuas Qhov rai (Qhov Loj Xa Tus Qauv Tsim)

5.6 Testing Qhov

2 pcs ntawm ¢ 400mmtesting lub qhov ntawm sab ntawm lub chamber,

Nrog silicon foob thiab stainless hlau npog.

5.7 Sealing

Txais yuav thawj cov roj hmab silicon cov roj hmab sawb, nrog kev ua haujlwm siab.

5.8 Tus Qauv Coj

Cov qauv siv nrog cov khoom siv rwb thaiv tsev, 2 txheej,

muaj peev xwm tsawg dua30kg \/ txheej.

5.9ightsing hauv chav nyob sab hauv

1 teeb tsa lub zog txuag hluav taws xob sab hauv lub qhov rais soj

5.10 TRI-xim teeb pom kev zoo

1 teeb tsa ntawm Tri-xim teeb lub tswb los qhia txog qhov xwm txheej khiav

5.11 Kev Nyab Xeeb Kev Nyab Xeeb

1 daim pa luam yeeb tso pa tawm.

2 daim ntawm tawg cov cuab yeej pov thawj saw ntawm Chamber sab.

1 teeb ntawm qhov tawg-pov thawj kub siab ntug qhov rooj.

6. Cua Khoom Siv Hluav Taws Xob

6.1 kev xa khoom

Kev quab yuam sab hauv los ntawm sab saud kom qis dua cov pa roj.

6.2 Cyclic Tsav

Taiwan hom tsis tshua muaj siab asynchronous tsav

6.3 blower

Zov feem ntau centrifugal ncig lub blower, siab qes. Resistant txhuas tuaj

6.4 Sensor

PT100 Sensor Kub (Cov Noob Ntub Dej Qhuav)

7.ERAUTFIGEER SYSTEM

Cua Txias Txuj Ci

Cua Txias Hom Hom Compressor

7.1 compressor

Lub teb chaws Yelemees gea boke lossis qib zoo sib xws compressor

7.2 tub yees

R448a

7.3 Condenser

Huab cua txias ua haujlwm siab yuam kev hais txog kev sib hais hom

7.4EVAPORATOR

Siab efficiency ntau-ntu Segment Tis Hom Evaporator

7.5

Roj Separator, thiab lwm yam ...

8. Cua sov system

8.1Heating raj

Naked Hlau Hom Nickel chromium alloy fais cua kub raj

9. maub los tswj & tswj circuit Court- maub los

9.1Controller

tus maub los

Rs {-485}} Chaw nres nkoj lossis LAN tsuas tuaj yeem xaiv tau ib qho ntawm lawv.

10.1 Kev Tiv Thaiv Kev Tiv Thaiv

1.With hnoos qeev anti-condensing, kev tiv thaiv kub tshaj-(

2. 2. Tsis muaj kev tiv thaiv fuse

3. Rhaub rau-temp. Kev Tiv Thaiv Hloov

4.Comressor over-load, tshaj cua sov

5. Compressor Siab Tiv Thaiv Kev Tiv Thaiv

6. Txheej Txheem Dua Kev Tiv Thaiv Tam Sim No

11. Lwm yam khoom siv ntxiv

11.1Cotion configuration

1.2 Cov Qauv Rwb thaiv tsev Rwb thaiv tsev, loading muaj peev xwm (nruab nrab) 30kg \/ txheej.

2.2 Corks rau txoj kab uas hla 50mm kuaj lub qhov.

3. Kev saib xyuas & txij nkawm phau ntawv qhia thiab tshuaj xyuas software

12. Kev khiav hauj lwm mob

1. Ib puag ncig temp. : 5 degree -35 degree;

2.Qhov av noo: tsawg dua los yog sib npaug rau 85% rh;

3.30Mospheric Siab: 80kpa ~ 106KPA

4. Txav deb ntawm kev co lub zog

5.Muaj cua ntau:

5.1.380V AC (± 10%), 50Hz 3 xaim 3 xaim 3 xaim - Cov xaim xaim, pob ntseg tsis zoo tsawg dua los yog sib npaug rau 4ω;
