Qauv: TOB-ET33 series
TOB-ET33 series ob channel muaj nuj nqi arbitrary waveform generator yog nruab nrog ncaj qha digital synthesis (DDS) thev naus laus zis uas ua rau cov teeb liab tso tawm kom ruaj khov thiab raug.

Xa kev nug

Tsham tam sim no

Khoom Taw qhia

Dual Channel DDS Function Arbitrary Waveform Generators

Specification

TOB-ET33 series ob channel muaj nuj nqi arbitrary waveform generator yog nruab nrog ncaj qha digital synthesis (DDS) thev naus laus zis uas ua rau cov teeb liab tso tawm kom ruaj khov thiab raug.

Cov yam ntxwv tseem ceeb:

Suav / Askiv zaub mov muaj

Nias qhov tseem ceeb rau kev pab thiab cov ntaub ntawv

Kev tswj cov ntaub ntawv txhawb nqa USB flash disk thiab chaw cia khoom hauv zos

Ob-channel tso zis nrog qhov tso zis ntau zaus yog ET3315 Qauv yog 15MHz, ET3325 Qauv yog 25MHz, ET3340 Qauv yog 40MHz, ET3360 Qauv yog 60MHz.

Tus nqi piv txwv: 200MSa / S, ntsug kev daws teeb meem: 13 ntsis thiab cia qhov tob: 8k

5 qhov yooj yim waveforms thiab 32 arbitrary waveforms hauv-ua

Pulse nthwv dej tso zis tau teem rau lub sijhawm ntug

Sab hauv / sab nraud AM, FM, PM, ASK, FSK thiab PSK kev ua haujlwm

Cov zis ntawm linear / logarithmic zaus cheb thiab tawg waveform

Zaus meter ntawm high precision ntawm 100MHz thiab 32-ntsis txee

Nrog RS232 interface, USB Device, USB Host interface txhawb USB flash disk cia (USB Host Yeem)

Multi-functional arbitrary waveform editing software nruab

General Technical Specifications:

Cov khoom siv hluav taws xob: 220V ± 10 feem pua, 45 ~ 65Hz, Los yog 110V ± 10 feem pua, 45 ~ 65Hz

Kev siv zog:< 15W

Hom: 3.5-inch TFT LCD npo, Kev daws teeb meem 480 × 320,16M xim

Ib puag ncig: Kev ua haujlwm 10 degree ~ ntxiv rau 40 degree, Tsis ua haujlwm -10 degree ~ ntxiv rau 60 degree

Humidity range: Hauv qhov ntau ntawm 0 ~ 40 degree, Tsawg dua lossis sib npaug rau 90％ txheeb ze av

Interface: RS232, USB ntaus ntawv; USB party (yeem)

Zaub: 3.5 nti TFT LCD npo, 480 x 320 daws teeb meem

Loj: 265 * 105 * 305mm (dav x qhov siab x tob)

Qhov hnyav: 2.6 kg

Cov yam ntxwv zaus
Qauv	TIAB SA 3315	TIAB SA 3325	TIAB SA 3340	TIAB SA 3360
Sine	1 μHz ~ 15 MHz	1 μHz ~ 25 MHz	1μHz ~ 40MHz	1μHz ~ 60MHz
Square	1 μHz ~ 15 MHz	1 μHz ~ 15 MHz	1 μHz ~ 15 MHz	1 μHz ~ 15 MHz
Daim duab peb sab	1 μHz ~ 15 MHz	1 μHz ~ 15 MHz	1 μHz ~ 15 MHz	1 μHz ~ 15 MHz
mem tes	100μHz ~ 6MHz	100μHz ~ 6MHz	100μHz ~ 6MHz	100μHz ~ 6MHz
Txiav txim	1 μHz ~ 6 MHz	1 μHz ~ 6 MHz	1 μHz ~ 6 MHz	1 μHz ~ 6 MHz
Suab nrov (-3dB)	7 MHz Bandwidth
Kev daws teeb meem zaus	1 μHz
Ntau zaus	± 5ppm
Zaus Stability	± 1ppm / 3 teev
Cov yam ntxwv zaus
Hom Waveform	Sine, square, daim duab peb sab, mem tes, suab nrov thiab arbitrary waves (xws li DC).
	Muaj 32 hom arbitrary nthwv dej thiab 50 hom kev siv cov nthwv dej.
Waveform Length	8 192 tzk
Waveform Sampling Rate	200 MSa/s
Waveform Vertical Resolution	13 bits
Sine Wave yam ntxwv
Sine Wave	Harmonic Distortion		Ntau dua lossis sib npaug rau 45dBc (<1MHz);
			Ntau dua lossis sib npaug rau 40dBc (1MHz ~ 20MHz)
	Tag nrho Harmonic Distortion		<0.8%(20Hz ~ 20kHz, 0dBm)
Square Wave Signal yam ntxwv
Square Wave	Nce / Poob		<20ns
	Overshoot		<5%
	Lub luag haujlwm Cycle		zaus<100kHz: 1%~99%;
			100kHz Tsawg dua los yog sib npaug rau freq<5MHz: 20% ~ 80%;
			5MHz Tsawg dua los yog sib npaug rau freq: 40 feem pua ~ 60 feem pua (0.1 feem pua daws teeb meem)
Pulse Wave yam ntxwv
Pulse Wave	Pulse Dav		Min 20 ns; 1ns daws
	Ntug Hloov Sijhawm		Min 20 ns;
	Overshoot		<5%
	Jitter		6ns ntxiv rau 0.1 feem pua Lub Sijhawm
Ramp Wave yam ntxwv
Ramp Wave	Linearity degree		Ntau dua lossis sib npaug li 98 feem pua (0.01Hz ~ 10kHz)
	Symmetry		{{0}}.0 ~ 100.0 feem pua (kev daws teeb meem 0.1 feem pua)
Cov yam ntxwv tso zis
Amplitude
Amplitude Range	zaus: 10 MHz		10MHz Tsawg dua lossis sib npaug rau zaus ~ 30MHz	30MHz Tsawg dua los yog sib npaug rau zaus
	2mVpp ~ 20Vpp		2mVpp ~ 10Vpp	2 mVpp ~ 5v np
Amplitude daws teeb meem	1mv ua
Amplitude Stability	±1% set value±1mVpp（1kHz Sine,0 offset,>10 mVpp)
Amplitude Flatness (kwv yees rau 1K Sine, 1 Vpp)	± 0.4dB<10MHz ;
	± 1.0dB Ntau dua lossis sib npaug rau 10MHz.
Cov zis impedance	50Ω ± 10% (Tswj)
Kev tiv thaiv	Tag nrho cov teeb liab tso zis davhlau ya nyob twg tuaj yeem luv luv hauv 60s
DC Offset
	Output Amplitude>0.1V		2mv ua
Offset Adjusting Range	± 10Vpk, ac plus dc		± 0.250Vpk, ac plus dc
Offset daws teeb meem	1mv ua
Cov yam ntxwv ntawm theem
Phase Adjusting Range	0 ~ 359.9 degree
Phase daws teeb meem	0.1 degree
Kev ntsuas sab nraud
Zaus Meter	Kev ntsuas zaus		1 Hz ~ 100 MHz
	ntau
	Kev ntsuas qhov tseeb		Lub sijhawm rooj vag hloov kho tsis tu ncua ntawm 0.01s ~ 10s
Counter Function	Suav cheeb tsam		0 ~ 4294967295
	Tswj hom		Kev tuav haujlwm
Input Signal Voltage Range	2 Vpp ~ 20 Vpp
Ua ke hom	AC lub DC
Pulse Width Measurement	1ns (kev daws teeb meem), 20s (MAX ntsuas lub sijhawm)
Kev ntsuas lub sij hawm	1ns (kev daws teeb meem), 20s (MAX ntsuas lub sijhawm)
SYNC tso zis
Tso zis Channel	CH1 lossis CH2, default CH1
Qib	TTL
Impedance	50Ω
Nce / Caij Nplooj Hlav	< 25ns
Ntau zaus	25 MHz
AM Modulation
Tso zis Channel	CH1 lossis CH2, default CH1
Carrier Wave	Sine, square, ramp, mem tes thiab arbitrary waveforms (tsis suav DC)
Qhov chaw	Sab hauv / Sab Nraud
Modulation Wave	Sine, square, daim duab peb sab thiab ramp
Modulation zaus	2mHz ~ 20kHz
Modulation Qhov tob	0 feem pua ~ 120 feem pua
FM Modulation
Tso zis Channel	CH1 lossis CH2, default CH1
Carrier Wave	Sine, square, ramp, mem tes thiab arbitrary waveforms (tsis suav DC)
Qhov chaw	Sab hauv / Sab Nraud
Modulation Wave	Sine, square, daim duab peb sab thiab ramp
Modulation zaus	2mHz ~ 20kHz
Zaus Offset	0~ Ntau tshaj tus neeg nqa khoom zaus
PM Modulation
Tso zis Channel	CH1 lossis CH2, default CH1
Carrier Wave	Sine, square, ramp, mem tes thiab arbitrary waveforms (tsis suav DC)
Qhov chaw	Sab hauv / Sab Nraud
Modulation Wave	Sine, square, daim duab peb sab thiab ramp
Modulation zaus	2mHz ~ 20kHz
Phase Offset	0 degree ~ 360 degree
NUG Modulation
Tso zis Channel	CH1 lossis CH2, default CH1
Carrier Wave	Sine, square, ramp, mem tes thiab arbitrary waveforms (tsis suav DC)
Qhov chaw	Sab hauv / Sab Nraud
Modulation Wave	Square yoj ntawm 50 feem pua lub luag haujlwm piv
Keying zaus	2mHz ~ 1MHz
Modulation Amplitude	0~ Tus neeg nqa khoom Amplitude
FSK Modulation
Tso zis Channel	CH1 lossis CH2, default CH1
Carrier Wave	Sine, square, ramp, mem tes thiab arbitrary waveforms (tsis suav DC)
Qhov chaw	Sab hauv / Sab Nraud
Modulation Wave	Square yoj ntawm 50 feem pua lub luag haujlwm piv
Keying zaus	2mHz ~ 1MHz
Hop zaus	Cov kab mob ntau zaus
PSK Modulation
Tso zis Channel	CH1 lossis CH2, default CH1
Carrier Wave	Sine, square, ramp, mem tes thiab arbitrary waveforms (tsis suav DC)
Qhov chaw	Sab hauv / Sab Nraud
Modulation Wave	Square yoj ntawm 50 feem pua lub luag haujlwm piv
Keying zaus	2mHz ~ 1MHz
Modulation Phase	0 degree ~ 360 degree
Zaus Sweep
Tso zis Channel	CH1 lossis CH2, default CH1
Hom	Linearity / Logarithm
Lub Sijhawm Sib Tw	1ms ~ 500{2}}s
Pib / Nres zaus	1µHz ~ Ntau tshaj cov neeg nqa khoom zaus
Sweep Direction	Forward, Backward
Nthuav qhov chaw	Kev tuav haujlwm, sab hauv, sab nraud
Cov yam ntxwv tawg
Tso zis Channel	CH1 lossis CH2, default CH1
Carrier Wave	Sine, square, ramp, mem tes thiab arbitrary waveforms (tsis suav DC)
Pulse suav	1 ~ 65535 lossis infinite, gated
Pib/Stop Phase	0 ~ 360 degree
Lub Sijhawm Sab Hauv	1μs~500s
Gating Source	Sab nraud
Nthuav qhov chaw	Sab hauv, sab nraud, phau ntawv ua haujlwm
Trigger Input
Teeb liab Range	2 Vpp ~ 20 Vpp
Kev sib txuas	AC lub DC
Pulse Dav	>100 nsq
Lub Sijhawm Tawm Tsam	<500ns（Burst）
	<10μs（Sweep）
Modulation Input
Impedance	1MΩ
Teeb liab ntau	± 2.5V ac ntxiv rau dc
