1. Daim Ntawv Thov: Supercapacitor Roll Groove Tshuab
2. Grooving Depth: 1.2-2 0mm adjustable
3. Grooving Dav: 1.5mm (Lub thickness ntawm lub hob yuav customized)
4. MOQ: 1 SET
5. Model: TOB-PGC1W

Xa kev nug

Tsham tam sim no

Khoom Taw qhia

Semi-auto Supercapacitor Lub tog raj kheej roj teeb Roll Grooving Groover Tshuab

Product Video

Specification

CE Certificate semi-auto grooving tshuab rau txhua yam cylindercial roj teeb 18650, 26650, CR123A thiab supercapacitor nrog hloov tuag.

SPECIFICATIONS

Functional Overview:

Nws yog siv nyob rau hauv cov txheej txheem channeling ntawm cylindrical roj teeb uas yog tsim nyob rau hauv lub laboratory thiab enterprise nyob rau hauv me me teev.

Functional yam ntxwv:

Cov pwm channeling uas tau nruab nrog 18650 cylindrical roj teeb;

Nws tuaj yeem siv rau hauv cov txheej txheem channeling ntawm lub plhaub steel ntawm 26650 thiab lwm yam cylindrical roj teeb los ntawm kev hloov pwm;

Qhov loj me ntawm cov channeling tuaj yeem hloov kho me ntsis, qhov loj me me, uas ua rau nws yooj yim rau kev khiav lag luam thiab cov tsos zoo nkauj;

Cov channeling yog siab precision thiab qhov ntev yog ruaj khov.

Qauv	TOB-PGC1W Roll Groove Tshuab
Lub zog	AC200V / 50HZ
Tag nrho lub zog	200W
Cua qhov chaw	0 5-0.7Mpa
Qhov tob ntawm qhov channeling	1. 2-2 0mm (adjustable)
Dav ntawm channeling	1.5mm (Lub thickness ntawm lub hob yuav customized)
Machining raug	± 0.1 hli
Hmoob life	>Ib lab zaug
Muaj peev xwm	semi-automatic 400 ea / h
Channeling pwm	18650, 26650, thiab lwm yam.
Channeling sijhawm	0-99s (kho tau)
Qhov ntev	720 (L) * 380 (W) * 480 (H) hli
Qhov hnyav	5 2 Kg
