Roj teeb Lub Nqus Sealer



Compact Battery Hnab Nqus Sealing Tshuab Siv





1 Lub hnab roj teeb lub tshuab nqus tsev sealing tshuab TOB-JK-200 feem ntau yog siv rau sealing aluminium-laminated rooj plaub hauv hnab looj tes tom qab txhaj tshuaj electrolyte rau hauv hnab Li-ion cell lossis tom qab tsim kev foob zaum kawg (polymer Li-Ion cell) .



2 Lub tshuab nqus tsev sealing yog nrog lub tshuab sealing thiab tswj lub thawv cais tsim, Thaum siv rau kev sib khi ua ntej, lub sealing tuaj yeem siv rau hauv lub hnab looj tes.



3 Rau kev sib khi zaum kawg, nws tuaj yeem siv rau kev sim lossis ua kom me me, yog tias muaj cov kab ntau lawm, Xav kom siv lub tshuab nqus tsev sealing rau lub hnab zaum kawg. (Lub tshuab nqus tsev yooj yim TOB-SVS system, Los yog Turntable hom nqus tshuab sealing TOB-TVS system)



Specifications

Qauv	Lub tshuab nqus tsev pre-sealing TOB-JK-200
Fais fab mov	110V-240V, xaiv tau, Ib Theem 50/60Hz
Hwj chim	1200W
Warranty	Ib Xyoo txwv warranty nrog kev txhawb nqa lub neej
Sealing Siab	Nqus chamber hau thiab sealing tuag yuav tsum tau tsav los ntawm compressed siab purity inert gases nrog pom zoo 60 psi
Nqus degree	-90kpa-0, kho tau
Sealing taub hau ntev	200 hli, customize
Sealing stamp dav	5 hli, customized
Sealing kub	RT-250 degree, kho tau nrog kev tswj qhov tseeb ntawm +/-2 degree
Cua sov Timer	0 - 99 vib nas this Kho tau
Huab cua	0 4-0.6MPa
Qhov Loj (L * W * H)	Sealing Unit: 600mm (L) x 300mm (W) x 500mm (H) Control Unit: 400mm (L) x 450mm (W) x 200mm (H)
Pob dimension	660 * 600 * 590 hli
Net nyhav	Sealing tshuab: 45kg Control lub thawv: 15kg
Pob hnyav	75kg ua
Accessories qhov chaw	1 daim cua sov yeeb nkab 3 meters foob cov khoom 1 daim intermediate relay 1 lub sij hawm relay 1 customized fais fab plug kab







;
