Roj teeb Sealing Packing Tshuab



Roj teeb Sealing Packing Tshuab





1 TOB-TSS-400 Battery Sealing

Tshuab yog lub tshuab cua sov ua kom sov rau sealing aluminium-laminated films

Thaum lub sij hawm lub hnab ntawm tes (polymer Li-Ion cell) cov ntaub ntawv npaj nrog 400mm ntev sealing bar.

2 Lub Roj Hmab Sealing Tshuab txais yuav mos sealing bar, Lub sealing yog tooj liab hauv qab thiab txhuas thiab Silicone

roj hmab daim rau saum. Yog li nws tuaj yeem siv rau ob sab saum toj thiab sab sealing rau lub hnab cell.

3 Nws tuaj yeem npaj lub hnab ntawm tes rau kev txhaj tshuaj electrolyte los ntawm kev sib khi rau sab thiab sab saum toj ntawm lub hnab cell nrog tab.

4 Lub sealing bar tuaj yeem hloov kho raws li qhov yuav tsum tau ua, Sealing taub hau ntev 200-400 hli customized, thiab peb tuaj yeem kho qhov sib txawv sealing dav hauv ib lub taub hau sealing.

Qauv	Roj teeb Sealing Tshuab TOB-TSS-400
Qhov chaw voltage	AC110V-240V, Customized
Cua sov yeeb nkab zog	1200W
Warranty	Ib Xyoo txwv warranty nrog kev txhawb nqa lub neej
Max sealing ntev	400 hli
Lub sijhawm sealing	0-99s tuaj yeem teeb tsa
sealing lub sij hawm raug	±0.1s
Sealing kub	0-250 degree
Kub tswj qhov tseeb	± 2 degree
Parallelism ntawm sab sauv thiab qis sealing taub hau	0.01 hli
Sealing stamp dav	6mm (customized)
Sealing stamp thickness	0 19-0.3 hli
Qhov Loj (L * W * H)	570 * 360 * 540 hli
Qhov hnyav	85kg ua
Shipping qhov ntev (L * W * H)	710 * 500 * 800 hli
Shipping hnyav	105kg ua
