Kub nias tshuab

Kab rov tav kub nias tshuab Rau mos-pob lithium-ion roj teeb yuav tsum tau tsim nyob rau hauv kub nias lub xeev

1. Cov khoom siv ua haujlwm

Cov khoom siv feem ntau yog siv rau cov roj teeb pob lithium-ion yuav tsum tau tsim nyob rau hauv lub xeev kub nias, uas tuaj yeem hloov cov txheej txheem ci ntawm cov txheej txheem tsim cov roj teeb uas twb muaj lawm, txo lub sijhawm tsim, txo cov roj teeb ntau lawm, txo cov kev ua haujlwm. , thiab qhov saum npoo ntawm lub roj teeb tom qab lub gas sealing zoo dua thiab zoo nkauj dua. Nyob rau tib lub sijhawm, nws ua tiav qhov tsim thiab compression molding ntawm lub roj teeb. Cov khoom siv no muaj 1 txheej ntawm cov txee tsim, 1 txheej clamp nrog 8 txheej.

Lub txee tshuaj muaj 16 txoj kab. Lub tshuab muaj peb qhov chaw: khib, sib sau clamps thiab fais fab mov. Nws muaj kev ua haujlwm ntawm cua sov, tswj qhov kub thiab txias, kev them nyiaj, kev sib txuas cov ntaub ntawv, kev sib txuas lus muaj nuj nqi kev ruaj ntseg, kev tiv thaiv muaj nuj nqi thiab hluav taws xob tswb.

2.Qhov loj ntawm cov khoom tuaj ntawm lub roj teeb tseem ceeb (mm): ntev 60 ~ 150; dav 28 ~ 120; thickness 2.5 ~ 11.

3.Kub nias kub ntau yam:

3.1 Kub nias kub tswj ntau yam: chav tsev kub +10 degree C ~ 90 degree C;

3.2 Kub nias kub tswj qhov tseeb: ± 4 degree C (qhov kub sib txawv ntawm cov txheej hauv tib txheej clamp);

3.3 Lub sijhawm ntsuas kub yog li 20 feeb (lub hom phiaj kub: 80 degree C);

4. Siab ib feem technical parameters:

4.1 Kev teeb tsa siab: 40 ~ 470kg;

4.2 Siab tswj qhov tseeb: ± 10kg;

4.3 Kev daws teeb meem siab: ± 1kg;

5. Ib puag ncig xav tau:

5.1 Ib puag ncig kub: 25 ± 15 ° C;

5.2 txheeb ze av noo: 30% -- 75%;

5.3 Atmospheric siab: 750 ± 30mmhg;

5.4 Compressed cua: 0.25 ~ 0.76Mpa;

5.5 Tsis muaj zog electromagnetic teb cuam tshuam thiab corrosive roj yaig;

5.6 Huab cua huv: ze rau 300, 000;

6. Lub zog yuav tsum muaj:Cov neeg muas zaub muab lub hwj chim txee

7. Lub sijhawm kho qhov tseeb:1 xyoo;

8.Channels:16 channels;

9. Kev tiv thaiv muaj nuj nqi

9.1 Kev tiv thaiv hluav taws xob:

9.1.1 Undervoltage qis txwv ceeb toom voltage, yuam voltage tiv thaiv;

9.1.2 Voltage thiab tam sim no volatility tiv thaiv;

9.1.3 Tshem tawm qhov hluav taws xob qis qis pom pom;

9.1.4 Kev tiv thaiv overvoltage;

9.1.5 Thawj qhov ntsuas hluav taws xob ua ntej ua ntej txheej txheem;

9.1.6 Voltage sab sauv txwv, lub sij hawm voltage, nrhiav tam sim no;

9.2 Kev Tiv Thaiv Kev Nyab Xeeb:

9.2.1 Tswb muaj nuj nqi: teeb lub tswb nrov, ceev xwm txheej;

9.2.2 Teem lub khawm nres thaum muaj xwm ceev, lub clamp yuav qhib tau thaum muaj xwm ceev nres;

9.2.3 Kev tiv thaiv hluav taws kub;

9.2.4 Tom qab cov khoom siv tswb raug tso tseg, cov txheej txheem tsis tiav tuaj yeem txuas ntxiv los ntawm txoj haujlwm cuam tshuam yam tsis tau pib txheej txheem txij thaum pib;

9.2.5 Yog tias kev sib txuas lus ntawm lub khoos phis tawj qis thiab lub khoos phis tawj sab saud raug cuam tshuam thiab kev sib txuas lus rov qab mus rau qhov qub, kev ua haujlwm tuaj yeem txuas ntxiv raws li tus txheej txheem qub;

9.2.6 Kev tiv thaiv kub dhau;

9.3 Kev tiv thaiv tsis muaj zog:

9.3.1 Tom qab lub zog tsis zoo ntawm lub cuab yeej tshwm sim, cov txheej txheem tam sim no tuaj yeem txuas ntxiv mus;

9.3.2 Thaum muaj lub sijhawm sib txuas lus cuam tshuam lossis lub PC tsis ua haujlwm, lub cuab yeej yuav cia li nkag mus rau lub xeev tos, thiab cov txheej txheem tam sim no yuav txuas ntxiv tom qab kev sib txuas lus sai sai.

10. Khoom siv installation yuav tsum

10.1 Kev teeb tsa siab segmentation, tsawg kawg yog peb ntu, qhov sib txawv ntawm qhov screen, lub sijhawm ntau;

10.2 Kub segmentation chaw, tsawg kawg yog peb ntu, deviation zaub, sijhawm ntau;

10.3 Tsis siv neeg kho lub siab raws li lub sijhawm them nyiaj;

10.4 Kho qhov kub thiab txias raws li lub sijhawm them nyiaj;

10.5 Them ua tiav, pib them nqi, tsis siv neeg cov cim qhia;

10.6 tswb system thiab cov ntaub ntawv (xws li pa luam yeeb, siab, kub, thiab lwm yam);

10.7 Lub tog raj kheej ua yeeb yam tso saib thiab qhov ntsuas.

Daim ntawv pov thawj Patent

ISO 9001 Cov

CE Daim Ntawv Pov Thawj
