Hloov Sib Nqus Txheej Tshuab
2.Cov txheej tuab yog yooj yim los kho, raug ntau dua, yooj yim rau kev khiav lag luam.it tuaj yeem ua ob qho tib si txuas ntxiv thiab txheej txheej.
Roll rau Roll Roj Teeb Electrode Nruam / Sib Nqus Txheej Tshuab (Max. 280mm Dav)
Product Video
Specification
Lub lithium roj teeb txheej tshuab TOB-ZST- 300-12M qauv txheej tshuab yog ib qho kev hloov mus tas li thiab sib cuam tshuam txheej tshuab tsuas yog siv rau Slurry ziab txheej txheem ntawm lithium roj teeb electrode txheej. Lub roj teeb txheej tshuab txais cov txheej txheem txuas ntxiv thiab sib cuam tshuam.
cov txheej tuab yog yooj yim los kho, ntau qhov tseeb, yooj yim rau kev khiav lag luam.it tuaj yeem ua ob qho tib si txuas ntxiv thiab txheej txheej.
| Qauv | TOB-ZST- 300-12M |
| Hwj chim | 3 PH 380V, 50HZ |
| Tsim nyog qhov system | LiFePO, lithium cobalt oxide, lithium manganese oxide system thiab txheej txheej txheem ntawm roj teeb anode thiab cathode |
| Cov khoom siv ua haujlwm thickness | Al foil: 10 ~ 30um Cu ntawv ci: 7 ~ 30um |
| Tus tsim ntawm yob nto dav | 300 hli |
| Guaranteed txheej dav | 50 ~ 280 hli |
| Mechanical khiav ceev ntawm cov khoom siv | 7m / min |
| Txheej ceev | 1-7m/min (Nyob ntawm qhov ziab kom qhuav) |
| Haum rau slurry viscosity | 2000 ~ 16000 hli |
| Ib txheej txheej thickness ntau | 50-150μm |
| Yam tsawg kawg ntawm qhov ntev | 5mm ua |
| Multi-section yam tsawg kawg nkaus txheej ntev | 20 hli |
| Solvent khoom | Oiliness hnyav NMP(sg{0}}.033,bp=204 degree) |
| Dej hnyav H2O/NMP(sg=1 {2}},bp=100 degree ) | |
| Tsim nyog cov ntsiab lus | Anode SC 60% ± 20% |
|
Cathode SC 60% ± 20% (PVDF system) SC 50% ± 5% (SBR system) |
|
| Tshwj xeeb lub ntiajteb txawj nqus | Anode 1.5-2.59 / cm2
Cathode 1 ~ 1.89 / cm2 |
| Txheej txheej | Ob chav sab 3 ntu, tsis sib xws sib tshuam hloov txheej / ob sab tsis siv neeg taug qab / txuas txuas ntxiv txheej |
| Base cov ntaub ntawv khiav kev taw qhia | Forward txheej, Cov khoom siv hauv qab khoob ntawv ci txav zoo, thim rov qab. |
| Tswj siab | 0 ~ 50N |
| Kho qhov sib txawv | EPC tswj, stroke 80mm |
| Qhov cub ntev | 12m |
| Khoom zoo | SUS304 stainless hlau, Sab hauv tank 1.0mm, sab nraud tank 1.2mm |
| Warranty | Ib xyoos txwv warranty nrog kev txhawb nqa lub neej |
