Lithium Ion Roj Teeb Ua Txheej Tshuab

1) Txheej dav: 300mm
2) Warranty: Ib Xyoo txwv warranty nrog kev txhawb nqa lub neej
3) Daim Ntawv Thov: Rau lithium roj teeb electrode txheej

Xa kev nug

Tsham tam sim no

Khoom Taw qhia

300mm Dav Lithium Roj Teeb Txheej Tshuab Nrog 6M Baking Cub

Specification

Lub lithium roj teeb txheej tshuab TOB-LIC-300 qauv txheej tshuab yog tsuas yog siv rau Slurry ziab txheej txheem ntawm lithium roj teeb electrode txheej.

Lub roj teeb electrode txheej tshuab txais lub sijhawm luv thiab txuas ntxiv txheej txheej, nws tuaj yeem txheej electrode nrog qhov dav thiab ntev rau cov txheej txheem winding lossis txheej txheem stacking.

Nruab nrog 3 ntu ci qhov cub rau 6M ntev, tuaj yeem qhuav cov electrode hauv qhov nrawm dua, nws yog siv rau cov roj teeb ntsuas ntsuas thiab kev tshawb fawb.

Rau kev tshawb fawb hauv chav kuaj, koj tuaj yeem xaiv TOB-VFC-150, TOB-XT-200CA. TOB-SY300J, TOB-TBJ-180C......

Qauv	Roj teeb Txheej Tshuab TOB-LIC300
Qhov chaw voltage	AC 220V / 110V, 50 / 60HZ
Warranty	Ib xyoos txwv warranty nrog kev txhawb nqa lub neej
Haum khoom dav	Aluminium ntawv nyiaj: 150-300mm, Copper foil: 150-300mm
Haum khoom thickness	Aluminium ntawv nyiaj: 11-30um, Copper foil: 9-30um
Haum cov khoom siv txoj kab uas hla	350 hli
Haum khoom hnyav	300 kg
Txheej thickness	Cathode : 50-150um, Anode : 60-180um
Txheej qhov sib txawv ntev	5-500 hli
Txheej ntev	50-3500 hli
Txheej ceev	Max 3m / min
Tshuab ceev	1. 5-5m/min
Qhov cub ntev	2m / ntu, 3 ntu qhov cub
Txheej raug	Hangover	Tsawg dua lossis sib npaug rau ± 1mm, raws li kev ua haujlwm slurry
	Lub taub hau, Tail, Ciam teb	Tsawg dua los yog sib npaug li 5 hli
	Ntev yuam kev	Tsawg dua los yog sib npaug rau ±0.75mm
	Txheej dav yuam kev	Tsawg dua los yog sib npaug rau ±0.5mm
	Thickness yuam kev	-15-5um
