LATP Khoom Lub Xeev Roj Teeb Electrolyte Sheet

1.Model: TOB-LATP-E01
2.Application: Rau lub xeev cov khoom siv roj teeb kev tshawb fawb thiab kev tsim khoom

Xa kev nug

Tsham tam sim no

Khoom Taw qhia

LATP Lithium Aluminium Titanium PhosphateKhoom Lub Xeev Roj Teeb Electrolyte Sheet

Specification

LATP khoom lub xeev roj teeb electrolytetau txais kev saib xyuas zoo heev vim nws cov tshuaj zoo heev thiab thermodynamic stability, tsis tshua muaj nqi raw khoom thiab nqi npaj. Nws yog cov khoom siv nano-solid electrolyte uas tuaj yeem siv rau kev npaj cov roj teeb tag nrho-lub xeev lithium-ion.

Qauv:TOB-LATP-E01

conductivity:2 * 10-4S/cm

Optional specifications:

1. Square 60 * 60mm

2. Ib thooj ntim nrog txoj kab uas hla ntawm 12mm * 260μm

3. Lwm qhov ntau thiab tsawg tuaj yeem hloov kho

Khoom npe	Lithium Aluminium Titanium Phosphate Solid State Roj teeb Electrolyte
Specification	Hloov daim ntawv, txoj kab uas hla 12mm, thickness 260μm
Theoretical ntom ntom	2.94 g / cm 2³
Tshuaj formula	Li_1.3Al_0.3Ti_1.7P₃O₁₂
Txee lub neej	1 xyoo

Cov khoom	Cov qauv tsim nyog	Chav tsev	Kev kuaj xyuas txoj kev
Thickness	260±10	μm	Micrometer
Txoj kab uas hla	12±0.1	mm	Vernier caliper
Qhov tshwm sim	Dawb, xim tsis sib xws	/	Kev tshuaj xyuas qhov muag
Lub ntsiab siv lead ua theem	Ua raws li tus yam ntxwv ncov ntawm PDF#35-0754	/	XRD
Ceramic qauv ion conductivity @ 25 degree	Ntau dua lossis sib npaug rau 0.45	mS/cm	AC impedance txoj kev
Flexural zog	Ntau dua lossis sib npaug li 130	MPa	Peb-point dabtsi yog khoov kuj
Qhov ntom	Ntau dua lossis sib npaug rau 2.793	g/cm³	Txoj kev lim dej
Qhov ntom ntom	Ntau dua lossis sib npaug li 95	%	Qhov ceev / theoretical ntom * 100%
Micromorphology	Magnification 20000, tsis ntau tshaj 3 qhov	/	SEM
