SIB 111

Model: TOB-NCM-111
Yam khoom: Lithium-ion roj teeb cathode ternary khoom

Xa kev nug

Tsham tam sim no

Khoom Taw qhia

SIB 111

Lub cev thiab tshuaj ntsuas ntsuas

Yam khoom		Txuj kev cai	Kev sim
Cov ntsiab lus tseem ceeb (%)	Li	7.3~7.9	ICP Test method
	Ni	20.6 ±1.00	ICP Test method
	Co	21.0±1.00	ICP Test method
	Mn	16.60 ± 1.00	ICP Test method
impurity yam (ug/g)	Fe	Tsawg dua los yog sib npaug li 30	ICP Test method
	Cu	Tsawg dua los yog sib npaug li 20	ICP Test method
	Zn	Tsawg dua los yog sib npaug li 20	ICP Test method
	S	Tsawg dua lossis sib npaug li 3500	ICP Test method
Particle loj faib (μm)	D10	Ntau dua lossis sib npaug li 2.5	Laser particle loj ntes
	D50	7.5±1.0	Laser particle loj ntes
	D90	Tsawg dua los yog sib npaug li 16	Laser particle loj ntes
Qhov chaw tshwj xeeb (m²/g）		0.25~0.45	Gas adsorption xeem
Kov ceev (g / cm³）		Tsawg dua lossis sib npaug li 2.20	Coj mus rhaub density tester
Cov ntsiab lus dej (ug / g)		Tsawg dua los yog sib npaug li 500	Karl Fischer Method
Li Dissolution nyiaj		Tsawg dua lossis sib npaug rau 0.25	785DMP TITRINO tsis siv neeg muaj peev xwm titrator
Tus nqi PH		Tsawg dua los yog sib npaug rau 12.0	Tus nqi PH
Sab nrauv		Cov hmoov dub tsis muaj impurities, tsis muaj agglomeration, tsis muaj agglomeration thiab tsis muaj qhov loj dua
*Peb lub tuam txhab cog lus tias tag nrho cov khoom lag luam ternary ua tau raws li cov kev cai cuam tshuam ntawm 《Txheej Txheem Kev Cai Lij Choj rau Cov Khoom Siv Hluav Taws Xob thiab Cov Khoom Siv Hluav Taws Xob nthuav tawm (SJ / T11363-2006)
