PE Separator

1.Model:TOB-PE-12
2. Thickness: 12 ± 1.5μm
3. Dav: 5 0.5 ± 0.2mm
4.MOQ: 1000M / yob

Xa kev nug

Tsham tam sim no

Khoom Taw qhia

12μm PE Roj Teeb Separator Rau Lithium ion roj teeb

PE Separator(TOB-PE-12)

Qhov project		Chav tsev	Technical ntsuas
dav		mm	50.5±0.2
tuab		ua um	12±1.5
Huab cua permeability		Seb / 100ml	150±50
porosity		%	40±5
Puncture zog		G	Ntau dua lossis sib npaug li 450
Areal ceev		g/m2	7.0±1.0
90 degree ± 2/2h Thaum tshav kub kub shrinkage tus nqi	TD	%	Tsawg dua los yog sib npaug li 1.5
90 degree ± 2/2h Thaum tshav kub kub shrinkage tus nqi	MD	%	Tsawg dua los yog sib npaug rau 4.0
tensile zog	TD	Kg f/cm2	Ntau dua lossis sib npaug li 150
tensile zog	MD	Kg f / cm2	Ntau dua los yog sib npaug rau 100
